60 Ton, BRUDERER, No. BSTA60, UNDER DRIVE HIGH SPEED PRESS
60 Ton, BRUDERER, No. BSTA60, UNDER DRIVE HIGH SPEED PRESS
Location:Ringwood, NJ
Description
60 TON BRUDERER PRECISION HIGH SPEED (4) PILLAR TYPE PUNCH PRESS MODEL BSTA60HL NEW APPROX. 1970 CAPACITY ---------------------------------- 60 TON STROKE ----- ( ADJUSTABLE ) --------------- .75" TO 3.00" ( 10 ADJUSTMENTS ) RAM ADJUSTMENT ---------------------------- 3.156" SHUT HEIGHT, RAM LDC, LOWER DEAD CENTER: STROKE AT 3/4" -------------------------- 8.5" TO 11.5" STROKE AT 3" ---------------------------- 7.25" TO 10.5" BED AREA ---------------------------------- 28.5" LR X 31" FB SLIDE FACE AREA --------------------------- 27.5" LR X 18" FB DISTANCE BETWEEN PILLARS ------------------ 31.5" LR X 13.4" FB SPEED ------ ( VARIABLE ) ----------------- 150 TO 580 SPM MAX. MATERIAL WIDTH ( OF BBV FEED ) ------- 11.75" MAX. MATERIAL FEED INDEX ( @ 650 SPM ) ---- 7.65" AIR CLUTCH AND BRAKE WITH SELECTOR CONTROLS NO FOUNDATION REQUIRED MAIN DRIVE MOTOR -------------------------- A.C. APPROXIMATE MACHINE WEIGHT ---------------- 19,200 LBS APPROXIMATE MACHINE DIMENSIONS ------------ 100"(LR) X 83"(FB) X 87"(H) EQUIPPED WITH --- 3" THICK BOLSTER PLATE HYDROSTATIC VARIABLE SPEED DRIVE UNDER DRIVEN DESIGN BRUDERER PRECISION ROLL FEED CYLINDRICAL POST GUIDES ELECTRICAL CONTROLS
Specifications
Manufacturer | BRUDERER |
Model | BSTA 60 |
Condition | Used |
Serial Number | NA |
Stock Number | 2027 |
